主要特点
▲真空加料机采用快装架构,与物料接触为优质奥氏体不锈钢材质。
▲设有料位感应器,感应灵敏,质量稳定。
▲独特采用高压旋涡气泵机,体积小,噪音小,寿命长。
▲全自动脉冲反吹系统自动清洗过滤器,保证设备持续运作而不堵塞。
▲自动化控制,自动完成加料、放料、反吹等周而复始的循环工作过程。
MAIN FEATURE
▲The vacuum feeder adopts a quick installed structure. The parts that contact materials are made of high quality austenitic stainless steel.
▲It is provided with material level sensor with good sensitivity and stable quality
▲It adopts unique high pressure vortex air pump, which is featured by small volume, low noise and long service life.
▲The automatic pulse back blowing system and automatic cleaning filter ensure that the equipment can run continuously without blocking.
▲Through automatic control, the repetitive work process such as feeding, discharging and back flowing are completed automatically.
技术参数TECHNICAL PARAMETERS | ||
型号Model | 整机功率Machine power(Kw) | 输送能力Conveying capacity(Kg/h) |
ZKS-1 | 1.5 | 400 |
ZKS-2 | 2.2 | 600 |
ZKS-3 | 3 | 1200 |
ZKS-4 | 5.5 | 2500 |
ZKS-6 | 5.5 | 3200 |
ZKS-7 | 7.5 | 6000 |
